| Item | Parameter |
|---|---|
| Model | AL3693-UV |
| Printhead | Type: EPSON I3200-U1/ EPSON I1600-U1 Quantity:2-4 |
| Print Area | 60cm*90cm |
| Print Height | 0-180mm |
| Resolution | 7201200DPI/ 7201800DPI / 720*2400DPI |
| Print Speed | Standard Mode: 7.5m²/h High-Resolution Mode: 4m²/h(Tested on linear printing without feather function) |
| Ink Type | UV Ink (K, C, M, Y, W, V, V1) |
| Print Solutions | W + KCMY; W + KCMY + V; W + W + KCMY + V; W+KCMY+V+V1 |
| RIP Software | FlexiPRINT, Fiery, Maintop, RIIN. |
| Transmit Port | Gigabit Ethernet |
| Print Media | Tile, Glass, Wood, Metal Sheet, Aluminum Composite Panel, Acrylic, UV Board, KT Board, Corrugated Board, Paper, etc. |
| Image Format | JPG, TIF, BMP, PDF, etc. |
| Computer Configuration | Operating System: Windows 7 and above; Hard Disk: 500G or more;GPU: ATI Mobility Radeon; RAM: 8G DDR4 or above |
| Working Environment | Temp.: 15℃ ~ 30℃, Humidity: 35% ~ 65% |
| Power | 110V/220V, 50-60HZ |
| Machine Size | Dimension: 178016251290mm |
| Weight | N.W: 430kg |
